– The Light Head Grid (LHG) is a compact and light wireless device with an integrated dual polarisation grid antenna at a revolutionary price
– It is perfect for point to point links or for use as a CPE
– LHG XL 2 is equipped with 21 dBi grid antenna for longer distances
Specifications
– Architecture: MIPSBE
– CPU: QCA9533
– CPU core count: 1
– CPU nominal frequency: 650 MHz
– Dimensions: fi 550×245 mm
– License level: 3
– Operating System: RouterOS
– Size of RAM: 64 MB
– Storage size: 16 MB
– Storage type: FLASH
– Tested ambient temperature: -40C to 70C
POWERING
– PoE in: Passive PoE
– PoE in input Voltage: 10-30V
– Number of DC inputs: 1 (PoE-IN)
– Max power consumption: 5W
WIRELESS
– Wireless 2.4 GHz number of chains: 2
– Wireless 2.4 GHz Max data rate: 300 Mbit/s
– Wireless 2.4 GHz standards: 802.11b/g/n
– Antenna gain dBi for 2.4 GHz: 21
– Wireless 2.4 GHz chip model: QCA9533
ETHERNET
– 10/100 Ethernet ports: 1
INCLUDED PARTS
– 24V 0.38A power adapter
– Metal rings (two)
– PoE injector
– K-LHG kit
