INTEL Core i3-13100 3.4Ghz FC-LGA16A Box, BX8071513100

CPU SPECIFICATIONS
– Total Cores: 4
– No. of Performance-cores: 4
– No. of Efficient-cores: 0
– Total Threads: 8
– Max Turbo Frequency: 4.50 GHz
– Performance-core Max Turbo Frequency: 4.50 GHz
– Performance-core Base Frequency: 3.40 GHz
– Cache: 12 MB Intel Smart Cache
– Total L2 Cache: 5 MB
– Processor Base Power: 60 W
– Maximum Turbo Power: 89 W

MEMORY SPECIFICATIONS
– Max Memory Size (dependent on memory type): 128 GB
– Memory Types
* Up to DDR5 4800 MT/s
* Up to DDR4 3200 MT/s
– Max No. of Memory Channels: 2
– Max Memory Bandwidth: 76.8 GB/s

PROCESSOR GRAPHICS
– Processor Graphics: Intel UHD Graphics 730
– Graphics Base Frequency: 300 MHz
– Graphics Max Dynamic Frequency: 1.50 GHz
– Graphics Output: eDP 1.4b, DP 1.4a, HDMI 2.1
– Execution Units: 24
– Max Resolution (HDMI): 4096 x 2160 @ 60Hz
– Max Resolution (DP): 7680 x 4320 @ 60Hz
– Max Resolution (eDP – Integrated Flat Panel): 5120 x 3200 @ 120Hz
– DirectX Support: 12
– OpenGL Support: 4.5
– OpenCL Support: 3.0
– Multi-Format Codec Engines: 1
– Intel Quick Sync Video: Yes
– Intel Clear Video HD Technology: Yes
– No. of Displays Supported: 4
– Device ID: 0x4692

EXPANSION OPTIONS
– Direct Media Interface (DMI) Revision: 4.0
– Max # of DMI Lanes: 8
– Scalability: 1S Only
– PCI Express Revision: 5.0 and 4.0
– PCI Express Configurations: Up to 1×16+4, 2×8+4
– Max No. of PCI Express Lanes: 20

PACKAGE SPECIFICATIONS
– Max CPU Configuration: 1
– Thermal Solution Specification: PCG 2020C
– TJUNCTION: 100°C
– Package Size: 45.0 mm x 37.5 mm

ADVANCED TECHNOLOGIES
– Intel Gaussian & Neural Accelerator: 3.0
– Intel Thread Director: No
– Intel Deep Learning Boost (Intel DL Boost): Yes
– Intel Speed Shift Technology: Yes
– Intel Turbo Boost Max Technology 3.0: No
– Intel Turbo Boost Technology: 2.0
– Intel Hyper-Threading Technology: Yes
– Intel 64: Yes
– Instruction Set: 64-bit
– Instruction Set Extensions: Intel SSE4.1, Intel SSE4.2, Intel AVX2
– Idle States: Yes
– Enhanced Intel SpeedStep Technology: Yes
– Thermal Monitoring Technologies: Yes
– Intel Volume Management Device (VMD): Yes

SECURITY & RELIABILITY
– Intel Threat Detection Technology (TDT): Yes
– Intel Standard Manageability (ISM): Yes
– Intel Control-Flow Enforcement Technology: Yes
– Intel AES New Instructions: Yes
– Secure Key: Yes
– Intel OS Guard: Yes
– Execute Disable Bit: Yes
– Intel Boot Guard: Yes
– Mode-based Execute Control (MBEC): Yes
– Intel Virtualization Technology (VT-x): Yes
– Intel Virtualization Technology for Directed I/O (VT-d): Yes
– Intel VT-x with Extended Page Tables (EPT): Yes
